Rugfone RK6

Rugfone RK6

4.0 inch Rugged 4G Keyboard Handheld terminal

More efficient operation improve enterprise Management


RK6 is a new generation latest Android 14.0 OS keyboard terminal, which has brand-new functions, enhanced big battery life 5000mAh

design. RK6 simplifies the operation of workers, and is more cost-effective. It provides more efficient operation options for workers in
different positions. Support NFC by ISO14443A/14443B/15693 protocol for retail payment management. With the help of RK6, it can
improve the efficiency of enterprise management.

Rugfone RK6
Rugfone RK6 Rugfone RK6 Rugfone RK6

KEY POINTS




  • Bright 4.0" inch key board with 5000mAh big battery

    Rugged and Durable MIL-STD-810G and IP67 protection level

    Multiple data connectivities:WI-FI2.4/5,4G/LTE DUAL SIM and Bluetooth 5.0

    Support Android™ 14 USB-C OTG, function keys

    Certification: GMS Google Play Store availability of apps and security

    Scan engine:with self developped scan engine almost any 1D/2D barcode within 200ms.

    NFC:Support security payment NXP557chip Protocol with ISO/ IEC14443A/IEC14443B/MiFare S50,S70

    Multi-Accessories for optional


Rugfone RK6

Characteristics


Techincal sheet

Processor


Octa-core 2.0GHz high-performance


Operating System


Android 14.0 (GMS)


Memory (ROM + RAM)


32GB+3GB (standard), 64G+4GB(optional)


Touch Panel


4-inch, resolution: 800*480 pixels

Capacitive Toughened glass TP support glove operation


Keypad 22 keypads


Front key*20, side scan key *2


Battery


3.85V lithium battery, with 5000mAh, detachable


Camera
Rear Camera  8MP Front Camera 5MP
Basic Functions
2G_3G_4G_BT Wifi GPS 3D accelerator,E-compass,Proximtity,Light sensor supported
GSM/3G/4G
GSM:2 3 5 8 WCDMA 1/5/8
4G: FDD-LTE,B1/B3/B5/B7/B8/B20/ TDD-LTE,B34/B38/B39/B40/B41


Wi-Fi Bluetooth
BT5.0  support(802.11 a/b/g/n/ac(2.4G + 5.8G dual-band Wi-Fi)
Sim card


SIM 1 card+TF 1 card,max 256GB


Charger


Type-C


Earphone


Type-C


Docking station charger
Optional


Audio Video
Audio coding  MPEG4
Video coding


3gp/H.263/MPEG4
Data collection
NFC (Note: Only 64GB+4GB version support NFC)

13.56MHz  reading distance within 50mm


Communication Protocol ISO14443A/14443B/15693


Scan engine
Self develop
LED
indicator light(red/green/blue)
Industrial and Reliability Design
Shake proof
1-19Hz/1.0mm; 19-200Hz/1.0g
Shock proof
MIL-STD-810G Method516.6  Procedure IV
Protection Grade
IP65
Operating temperature
-20  to 55
Storage Temperature
-40 to 80
RH
5 to  percent
Operating Altitude
Max4500m  15000 feet
ESD
Air discharge no more than 15000V  contact discharge no more than 8000V
Size/Package
165mm x 67mm x 19mm


Body weight
279g
Warranty
warranty 24 months
Package
USB data cable X1 ,charger 5V 2A X1,UM X1, hand strap X1


Accessories


What is in the box
